| Part No | 90PF05M1-M02T10 |
| Sales Model Name | D501SER-514500127W |
| EAN Code | |
| UPC Code | |
| WEEE | 6 |
| BASE UNIT | VSPF05M1-BU0010 |
| Size | 8.6L |
| Color | Black |
| Form Factor | Small form factor |
| Operating System | Windows 11 Home - ASUS recommends Windows 11 Pro for business |
| Office | 1-month trial for new Microsoft 365 customers. Credit card required. |
| Processor | Intel® Core™ i5-14500 Processor 2.6GHz (24MB Cache, up to 5.0GHz, 14 cores, 20 Threads) N/A |
| CPU Cooler | Air Cooler |
| Chipset | Intel® B760 Chipset |
| DIMM Memory | 8GB DDR5 U-DIMM + 8GB DDR5 U-DIMM |
| Memory Speed | Memory speed is 5600MHz, but run at 4000~4400MHz. |
| Memory Max. | 64GB |
| Integrated GPU | Intel® UHD Graphics 770 |
| Storage | 512GB M.2 2280 NVMe™ PCIe® 4.0 SSD |
| Optical Drive | Without optical drive |
| LAN | Intel WGI219V 10/100/1000 Mbps, non-vPro |
| Audio | High Definition 7.1 Channel Audio |
| Power Supply | 330W power supply (80+ Platinum, peak 660W) |
| Rear I/O Port | 1x RJ45 Gigabit Ethernet 1x HDMI 1.4 1x VGA Port 1x 7.1 channel audio (microphone, line-out, Line-in) 1x Kensington lock 1x Padlock loop 2x USB 2.0 Type-A 2x USB 3.2 Gen 1 Type-A 1x FLEX I/O port (HDMI 2.1 TMDS) |
| Front I/O Port | 1x Headphone 1x 3.5 mm combo audio jack (Mic in or Headphone out) 2x USB 2.0 Type-A 2x USB 3.2 Gen 2 Type-A |
| Drive Bay | 2.5" x 1 3.5" x 1 |
| Serial ATA | 4 x SATA 6.0Gb/s ports |
| Expansion Slot(includes used) | 1x PCIe® 4.0 x 16 2x PCIe® 3.0 x 1 1x M.2 2230 connector for storage 1x M.2 2280 connector for storage 1x M.2 connector for WiFi 2x DDR5 U-DIMM slot |
| Keyboard & Mouse | Wired keyboard (USB) Wired optical mouse (USB) |
| Dimension (WxDxH) | 09.30 x 29.60 x 30.90 cm (3.66" x 11.65" x 12.17") |
| Weight | 06.00 kg (13.23 lbs) |
| My ASUS features | System diagnosis Fan profile AppDeals |
| Built-in Apps | MyASUS ASUS Business Manager |
| Adobe Creative Cloud Hard Bundle | 1-month Adobe Creative Cloud Hard Bundle *Terms and exclusions apply. Offer only available in eligible markets. Eligible markets are determined at activation, and varies by region, device, and time. |
| Security | HDD User Password Protection and Security Kensington Security Slot™(7x 3mm) Padlock loop Trusted Platform Module (Firmware TPM) |
| Antivirus | N/A |
| TPM | Trusted Platform Module (TPM) 2.0 |
| Ecolabels & Compliances | EPEAT Silver Energy star 8.0 REACH RoHS |
| Base Warranty | 3Y OnSite Service |
| Recommended Warranty Package Part number//Extension and/or upgrade service from base warran | *If you would like to know the details, please contact your sales teams. |
| Sustainable Material_Front bezel | 65% PCR recycled plastic front bezel |
