| Part No | 90PF05D1-M02PN0 |
| Sales Model Name | D700MF-007265153W |
| EAN Code | |
| UPC Code | |
| WEEE | |
| BASE UNIT | VSPF05D1-BU0010 |
| Size | 15L |
| Color | Black |
| Form Factor | Mini tower |
| Operating System | Windows 11 Home - ASUS recommends Windows 11 Pro for business * Windows 11 Home is available only as the Single Language edition. Learn more about Windows 11 Home Single language: https://support.microsoft.com/article/eaf060a6-3642-4612-6b75-b34e57a08abf |
| Office | 1-month trial for new Microsoft 365 customers. Credit card required. |
| Processor | Intel® Core™ Ultra 7 Processor 265 2.4GHz (30MB Cache, up to 5.3GHz, 20 cores, 20 Threads) N/A |
| Neural processor | Intel® AI Boost NPU |
| CPU Cooler | Air Cooler |
| Chipset | Intel® B860 Chipset |
| DIMM Memory | 16GB DDR5 U-DIMM *2 |
| Memory Speed | Memory speed is 5600 MT/s, but clock down by processor setting. |
| Memory Max. | 128GB |
| Graphics | NVIDIA® GeForce RTX™ 5060 DUAL 8GB GDDR7 : 3xDP, 1x HDMI |
| Integrated GPU | Intel® UHD Graphics |
| Storage | 2TB SATA 7200RPM 3.5" HDD 512GB M.2 2280 NVMe™ PCIe® 4.0 SSD |
| Optical Drive | Without optical drive |
| LAN | Intel WGI219V 10/100/1000 Mbps, non-vPro |
| Audio | High Definition 7.1 Channel Audio |
| Wireless | Wi-Fi 6E(802.11ax) (Triple band) 2*2 + Bluetooth® 5.4 Wireless Card |
| Power Supply | 500W power supply (80+ Platinum, peak 1000W) |
| Rear I/O Port | 1x RJ45 Gigabit Ethernet 1x HDMI 1.4 1x VGA Port 1x Displayport 1.4 1x 7.1 channel audio (microphone, line-out, Line-in) 1x Kensington lock 1x Padlock loop 3x USB 2.0 Type-A (480 Mbps) 2x USB 3.2 Gen 1 Type-A (5 Gbps) 1x FLEX I/O port (DP1.4 HBR3) |
| Front I/O Port | 1x Headphone 1x 3.5mm combo audio jack 2x USB 2.0 Type-A (480 Mbps) 2x USB 3.2 Gen 2 Type-A (10 Gbps) 1x USB 3.2 Gen 2x2 Type-C (20 Gbps) 1x 2 in 1 card reader SD / MMC 1x Smart card reader |
| Drive Bay | 2.5" x 1 3.5" x 1 |
| Serial ATA | 4 x SATA 6.0Gb/s ports |
| Expansion Slot(includes used) | 1x PCIe® 3.0 x 1 1x PCIe® 4.0 x 16 1x M.2 2280 connector for storage 1x M.2 2280/2230 connector for storage 1x M.2 connector for WiFi 4x DDR5 U-DIMM slot |
| Keyboard & Mouse | Wired keyboard (USB) Wired optical mouse (USB) |
| Keyboard language | English International |
| Accessory | Internal Speaker 3.5" HDD assembly kit |
| Dimension (WxDxH) | 15.50 x 29.60 x 34.70 cm (6.10" x 11.65" x 13.66") |
| Weight | 06.00 kg (13.23 lbs) |
| My ASUS features | System diagnosis Fan profile AppDeals Link to MyASUS |
| MyExpert Features | ExpertMeet(All) |
| Built-in Apps | AI ExpertMeet (AI features need devices with 12GB RAM or more) MyASUS ASUS Business Manager |
| Adobe Creative Cloud Hard Bundle | 1-month Adobe Creative Cloud Hard Bundle *Terms and exclusions apply. Offer only available in eligible markets. Eligible markets are determined at activation, and varies by region, device, and time. |
| Security | Discrete Trusted Platform Module (TPM) 2.0 HDD User Password Protection and Security Kensington Security Slot™(7x 3mm) Padlock loop |
| Antivirus | McAfee® 30 days free trial |
| Ecolabels & Compliances | EPEAT Silver Energy star 9.0 REACH RoHS |
| Base Warranty | 3Y OnSite Service |
| Recommended Warranty Package Part number//Extension and/or upgrade service from base warran | *If you would like to know the details, please contact your sales teams. |
| Sustainable Material_Front bezel | 65% PCR recycled plastic front bezel |
| Sustainable Material_I/O bezel | 65% PCR recycled plastic I/O bezel |
